Swing LR 500 Rural Gate Opener with Main Power Kit

MRGLSK-MP



Description:


Experience effortless, dependable access with the Merlin Swing LR 500 Swing Gate Opener — a farm rural gate opener engineered for reliability, convenience and all-weather performance. Created specifically for wide and rural farm gates alike, it offers a simple transition from manual to automatic operation, giving you consistent, smooth access to your property.

Ideal for locations with mains power, this farm gate opener connects easily through a plug-and-play setup. Whether you’re dealing with downpours, heatwaves or frosty winter mornings, the LR 500 delivers consistent operation across all seasons. Even during power outages, the optional battery backup will keep your rural farm gates operational without interruption. Backed by a 3-year Merlin warranty, the LR 500 combines practical design with long-term durability, making it the perfect solution when you’re seeking reliable access control tailored to rural lifestyles. Invest in your comfort, convenience and peace of mind today with the Merlin Swing LR 500 Swing Gate Opener.

  • Product Features
  • Specifications
  • Included Accessories
  • Downloads

Maximum Gate Width
-200kg for 5m gate
-250kg for 4m gate
-300kg for 3m gate

Maximum width for single gate: 5m

General

Door Specs

Door Opening and Closing Times

Door Height

Standard Specifications - Main AC Supply: 240 VAC; 50/60Hz - Motor Voltage: 24 VDC - Input Power: 50 W - Ambient Temperature Range: -20 - +55*C -Max peak pulling force: 1,500Nm -Travel Speed:Opens 120' in 20-27 seconds -Radio Frequency: 433.30, 433.92, 434.54 MHz with Security+ 2.0 technology -Compatible with myQ technology -Gate opener capacity of up to 64 memory registers -IP44 Weather Resistant

2 x E975M

Logic Box

Main Power Kit
